Eurotec Paneltwistec, construction screw, yellow zinc plated

Size and packaging:
3,5x30 mm (1000)7 - 14 days 0.000
3,0x35 mm (1000)7 - 14 days 3.100
3,5x40 mm (1000)7 - 14 days 4.700
3,5x50 mm (500)7 - 14 days -5.300
4,0x30 mm (1000)7 - 14 days 4.100
4,0x35 mm (1000)7 - 14 days 7.400
4,0x40 mm (1000)7 - 14 days 10.100
4,0x45 mm (500)7 - 14 days -4.000
4,0x50 mm (500)7 - 14 days -2.500
4,0x60 mm (200)7 - 14 days -12.300
4,0x70 mm (200)7 - 14 days -10.600
4,0x80 mm (200)7 - 14 days -5.800
4,5 x 35 mm (500)7 - 14 days -4.500
4,5 x 40 mm (500)7 - 14 days -1.800
4,5 x 45 mm (500)7 - 14 days 0.000
4,5 x 50 mm (500)7 - 14 days 2.400
4,5 x 60 mm (200)7 - 14 days -10.200
4,5 x 70 mm (200)7 - 14 days -8.400
4,5 x 80 mm (200)7 - 14 days -5.400
5,0x40 mm (200)7 - 14 days -11.300
5,0x50 mm (200)7 - 14 days -9.500
5,0x60 mm (200)7 - 14 days -7.400
5,0x70 mm (200)7 - 14 days -5.000
5,0x80 mm (200)7 - 14 days -1.800
5,0x90 mm (200)7 - 14 days 2.200
5,0x100 mm (200)7 - 14 days -0.100
5,0x120 mm (200)7 - 14 days 6.400
6,0x60 mm (200)7 - 14 days -5.100
6,0x70 mm (200)7 - 14 days -3.000
6,0x80 mm (200)7 - 14 days 0.200
6,0x90 mm (100)7 - 14 days -9.200
6,0x100 mm (100)7 - 14 days -6.900
6,0x110 mm (100)7 - 14 days -4.500
6,0x120 mm (100)7 - 14 days -3.000
6,0x130 mm (100)7 - 14 days -1.100
6,0x140 mm (100)7 - 14 days 1.100
6,0x150 mm (100)7 - 14 days 4.500
6,0x160 mm (100)7 - 14 days 6.800
6,0x180 mm (100)7 - 14 days 16.200
6,0x200 mm (100)7 - 14 days 19.800
6,0x220 mm (100)7 - 14 days 29.500
6,0x240 mm (100)7 - 14 days 41.500
6,0x260 mm (100)7 - 14 days 56.600
6,0x280 mm (100)7 - 14 days 65.700
6,0x300 mm (100)7 - 14 days 68.600
8,0x80 mm (50)7 - 14 days -9.700
8,0x100 mm (50)7 - 14 days -6.900
8,0x120 mm (50)7 - 14 days -4.300
8,0x140 mm (50)7 - 14 days -2.400
8,0x160 mm (50)7 - 14 days -1.000
8,0x180 mm (50)7 - 14 days 3.600
8,0x200 mm (50)7 - 14 days 6.200
8,0x220 mm (50 ks)7 - 14 days 10.700
8,0x240 mm (50)7 - 14 days 15.500
8,0x260 mm (50)7 - 14 days 18.900
8,0x280 mm (50)7 - 14 days 24.000
8,0x300 mm (50)7 - 14 days 28.800
8,0x320 mm (50)7 - 14 days 32.400
8,0x340 mm (50)7 - 14 days 39.600
8,0x360 mm (50)7 - 14 days 43.500
8,0x380 mm (50)7 - 14 days 46.900
8,0x400 mm (50)7 - 14 days 52.300
10,0x100 mm (50)7 - 14 days -2.300
10,0x120 mm (50)7 - 14 days 2.500
10,0x140 mm (50)7 - 14 days 5.300
10,0x160 mm (50)7 - 14 days 11.600
10,0x180 mm (50)7 - 14 days 19.600
10,0x200 mm (50)7 - 14 days 26.300
10,0x220 mm (50)7 - 14 days 32.100
10,0x240 mm (50)7 - 14 days 38.800
10,0x260 mm (50)7 - 14 days 47.200
10,0x280 mm (50)7 - 14 days 53.500
10,0x300 mm (50)7 - 14 days 59.400
10,0x320 mm (50)7 - 14 days 73.000
10,0x340 mm (50)7 - 14 days 78.100
10,0x360 mm (50)7 - 14 days 84.300
10,0x380 mm (50)7 - 14 days 88.000
10,0x400 mm (50)7 - 14 days 92.600
Producer: Eurotec
Warranty: 24 months
Code: 903025
Availability: 7 - 14 days
Watchdog Add to wishlist Share

Eurotec Paneltwistec, construction screw, yellow zinc plated

Material: hardened steel, yellow zinc plated

Application:

  • anchoring of wooden structures, construction of wooden buildings and wooden houses
  • timber - timber joint
  • quality universal screw with certificate



Specific features of the screw:

  • ribbs under the head - anchoring without cracks and crevices
  • drill tip for fast drilling of the screw
  • cutter above the thread diverts chips (speeds up assembly)
  • lower tightening torque required, saves your strength and tools
  • TORX screw drive - no slippage when screwing



Professional screws with CE certification





Size (mm) Head diameter (mm) Thread length (mm) Torx Package (pcs.)
3,5 x 30  7,0  18 TX20 1000
3,5 x 35  7,0  21 TX20 1000
3,5 x 40  7,0  24 TX20 1000
3,5 x 50  7,0  30 TX20 500
4,0 x 30  8,0  18 TX20 1000
4,0 x 35  8,0  21 TX20 1000
4,0 x 40  8,0  24 TX20 1000
4,0 x 45  8,0  27 TX20 500
4,0 x 50  8,0  30 TX20 500
4,0 x 60  8,0  36 TX20 200
4,0 x 70  8,0  42 TX20 200
4,0 x 80  8,0  48 TX20 200
4,5 x 35  9,0  24 TX20 500
4,5 x 40  9,0  27 TX20 500
4,5 x 45  9,0  30 TX20 500
4,5 x 50  9,0  36 TX20 500
4,5 x 60  9,0  42 TX20 200
4,5 x 70  9,0  48 TX20 200
4,5 x 80  9,0    TX20 200
5,0 x 40  10,0  27 TX20 200
5,0 x 50  10,0  30 TX20 200
5,0 x 60  10,0  36 TX20 200
5,0 x 70  10,0  42 TX20 200
5,0 x 80  10,0  48 TX20 200
5,0 x 90  10,0  54 TX20 200
5,0 x 100 10,0  60 TX20 200
5,0 x 120 10,0  70 TX20 200
6,0 x 60  12,0  36 TX30 200
6,0 x 70  12,0  42 TX30 200
6,0 x 80  12,0  48 TX30 200
6,0 x 90  12,0  54 TX30 100
6,0 x 100 12,0  60 TX30 100
6,0 x 120  12,0  70 TX30 100
6,0 x 130  12,0  70 TX30 100
6,0 x 140  12,0  70 TX30 100
6,0 x 150  12,0  70 TX30 100
6,0 x 160  12,0  70 TX30 100
6,0 x 180  12,0  70 TX30 100
6,0 x 200  12,0  70 TX30 100
6,0 x 220  12,0  70 TX30 100
6,0 x 240  12,0  70 TX30 100
6,0 x 260  12,0  70 TX30 100
6,0 x 280  12,0  70 TX30 100
6,0 x 300  12,0  70 TX30 100
8,0 x 80  14,5  48 TX40 50
8,0 x 100 14,5  54 TX40 50
8,0 x 120  14,5  60 TX40 50
8,0 x 140  14,5  80 TX40 50
8,0 x 160  14,5  80 TX40 50
8,0 x 180  14,5  80 TX40 50
8,0 x 200  14,5  80 TX40 50
8,0 x 220  14,5  80 TX40 50
8,0 x 240  14,5  80 TX40 50
8,0 x 260  14,5  80 TX40 50
8,0 x 280  14,5  80 TX40 50
8,0 x 300  14,5  80 TX40 50
8,0 x 320  14,5  80 TX40 50
8,0 x 340  14,5  80 TX40 50
8,0 x 360  14,5  80 TX40 50
8,0 x 380  14,5  80 TX40 50
8,0 x 400  14,5  80 TX40 50
10,0 x 100 17,5  60 TX50 50
10,0 x 120 17,5  90 TX50 50
10,0 x 140  17,5  90 TX50 50
10,0 x 160  17,5  90 TX50 50
10,0 x 180  17,5  90 TX50 50
10,0 x 200  17,5  90 TX50 50
10,0 x 220  17,5  90 TX50 50
10,0 x 240  17,5  90 TX50 50
10,0 x 260  17,5  90 TX50 50
10,0 x 280  17,5  90 TX50 50
10,0 x 300  17,5  90 TX50 50
10,0 x 320  17,5  90 TX50 50
10,0 x 340  17,5  90 TX50 50
10,0 x 360  17,5  90 TX50 50
10,0 x 380  17,5  90 TX50 50
10,0 x 400  17,5  90 TX50 50
