Eurotec PediX - post support for construction wood (1 pc.)
Eurotec PediX - post support for construction wood
Material: hot-dip galvanized steel
Aplication: anchoring of columns, beams or wooden beams, wooden beams can be additionally finely adjusted thanks to the adjustment mechanism hidden under the sleeve. A very aesthetic and functional solution for the visible anchoring of wooden poles.
Thanks to the re-screwing of the joint with the wood in several directions, the structure of the wood is not disturbed and the natural strength of the wood is not weakened.
High-quality stainless steel wood screws (A2 5.0x80 mm) from Eurotec are always included.
For fixing the foot of the Eurotec PediX post you can use high-quality concrete screws, also from Eurotec.
Adjustable height (mm) | Min. dimension of the wood (mm) | Size (mm) | |
PediX 140+50 | 140-190 | 100 x 100 | 160 x 100 x 8 |
PediX 190+100 | 190-290 | 100 x 100 | 160 x 100 x 8 |
PediX 300+150 | 300-450 | 100 x 100 | 160 x 100 x 8 |
PediX B500 | 500 | 100 x 100 | |
PediX B500+50 | 550 | 100 x 100 |
Packing: 1 pcs (including screws for prism and washer)
Stainless steel screws for concrete can be purchased (140-190 = 2 pc., 190-290 = 4 pcs.)
Installation video and product overview:
