SIHGA EDSTAHL - stainless steel adjustable beam post

Height adjustable beam post. The height can be additionally adjusted thanks to a mechanism hidden under the stainless steel sleeve. The mechanism is protected by a rubber seal, which prevents rusting of the adjustment mechanism). A luxurious and functional solution for pergolas, gazebos or carports.

Adjustment range: 125-170 mm (EDSTAHL 300)

                                     160-225 mm (EDSTAHL 400)

Certified solution (ETA certificate).

Technical data: download the technical data sheet here

Material: stainless steel (100% eliminates the risk of corrosion)

Size of anchor plate: 160x80 mm (EDSTAHL 300)

                                        160x100 mm (EDSTAHL 400)

Number/diameter of holes in the anchor plate: 2 holes/diameter 13 mm (EDSTAHL 300)

                                                                                           4 holes/diameter 13 mm (EDSTAHL 400)

Number of pieces in the package: EDSTAHL 300 - 1 piece foot plate, 2 pieces concrete screws 10x95 mm, 4 pieces stainless steel wood screws 6x160 mm

                                                                 EDSTAHL 400 - 1 pcs foot, 4 pcs concrete screws 10x95 mm, 4 pcs stainless steel wood screws 6x160 mm
