Stainless steel dowels 6-8 mm (100/200 pcs.)
Stainless steel dowels 6-8mm
Material: nylon PA6 (dowel) , stainless steel A2 (screw)
Used for quick fixing to the substrate. Can be loaded immediately. The anchor/lock is activated by a blow. The recessed head of the screw and the shape of the dowel collar is ideal for anchoring wood-based materials, the dowel does not protrude from the substrate once fitted.
Packing: 100/200 pcs (depending on size)
Dimension | d | d0 - hole diameter | ds - screw diameter | h1 - Length | hef - length in the substrate | l - Length | ls - screw length | tfix - material thickness |
6x40 mm | 6 mm | 6 mm | 4 mm | 40 mm | 30 mm | 40 mm | 45 mm | 15 mm |
6x60 mm | 6 mm | 6 mm | 4 mm | 40 mm | 30 mm | 60 mm | 65 mm | 35 mm |
6x80 mm | 6 mm | 6 mm | 4 mm | 40 mm | 30 mm | 80 mm | 85 mm | 55 mm |
8x60 mm | 8 mm | 8 mm | 5 mm | 50 mm | 40 mm | 60 mm | 65 mm | 20 mm |
8x80 mm | 8 mm | 8 mm | 5 mm | 50 mm | 40 mm | 80 mm | 85 mm | 40 mm |
8x100 mm | 8 mm | 8 mm | 5 mm | 50 mm | 40 mm | 100 mm | 105 mm | 60 mm |
8x120 mm | 8 mm | 8 mm | 5 mm | 50 mm | 40 mm | 120 mm | 125 mm | 60 mm |
8x140 mm | 8 mm | 8 mm | 5 mm | 50 mm | 40 mm | 140 mm | 145 mm | 60 mm |
Professional dowel with CE/ETA certification. Made in EU.
