Rod dowel- Eurotec EST (50 pcs.)
Rod dowel- Eurotec EST
EUROTEC EST self-tapping pins (screws) are most often used together with the EUROTEC T-Profile aluminium bracket. They are used to create an invisible connection of the prism to another supporting structure (concrete, timber, CLT, main beam, etc.).
The Eurotec EST self-drilling screw is a double-threaded screw with an innovative arrow drill and a specially developed chip-removal groove. The double-threaded screw has a cylindrical head with integrated TX drive. The special geometry of the arrow drill bit ensures a lower chipping effect when screwing. The chip removal groove ensures optimised screwdriving behaviour.
Material: hardened carbon steel
CE-certified - quality component for wood construction
Usage:
- corrosion resistance
- suitable for classes of operation 1 and 2 according to DIN EN 1991
- good resistance to mechanical stress
Advantages:
- no pre-drilling required
- innovative arrow drill bit for screwdriving without damaging the wood
- screws do not jam together when screwdriving with the TX drive
Packaging: 50 pcs.
dimensions (mm) | thread length down/up (mm) | head diameter (mm) | torx |
7,5x73 | 27/0 | 12 | T40 |
7,5x93 | 27/8,5 | 12 | T40 |
7,5x113 | 36/12,5 | 12 | T40 |
7,5x133 | 36/12,5 | 12 | T40 |
7,5x153 | 36/12,5 | 12 | T40 |
7,5x173 | 36/12,5 | 12 | T40 |
7,5x193 | 36/12,5 | 12 | T40 |
7,5x213 | 36/12,5 | 12 | T40 |
7,5x233 | 36/12,5 | 12 | T40 |
