Angle Bracket Screw – Blue Zinc Plated

The angle bracket screw made of hardened carbon steel is designed for steel-to-wood connections, such as angle brackets, joist hangers, and metal connectors. The specially shaped tip reduces wood splitting and ensures precise and fast installation.

The smooth shank under the head provides reliable load transfer in shear, while the thread efficiently transfers tensile forces. The screw is suitable for structural connections in timber construction and carpentry applications.

Packaging: 250 pcs

Main advantages

• reduced wood splitting
• fast and easy installation
• high strength in shear and tension
• suitable for steel-to-wood connections
• ETA approved

Technical information

• Material: hardened carbon steel, blue zinc plated
• Application: service classes 1 and 2 (indoor, protected outdoor)
• Drive: TX20
• Diameter: 5.0 mm
• Lengths: 25–70 mm
• ETA: ETA-11/0024

Applications

• angle brackets and metal connectors
• joist hangers
• timber structures
• carpentry connections
